Vitacci 110cc ATV

ENGINE INFO

CHASSIS ETC

Engine type:

single cylinder, 4 stroke, air-cooled

Clutch:

Automatic

Displacement:

107

Transmission:

Chain

Max torque:

6.18/5500±500(N.m/r/min)

Brakes;

Front/Rear:

hub/hydraulic disc

Bore stroke:

52.4 x 49.5mm

Tires;

front/rear:

145/70-6 145/70-6

Max speed:

55km/h

Fuel capacity:

2.4L

Climbing ability

Weight:

G.W/N.W

154 lbs/176 lbs

Ignition:

CDI

Max load:

60kg

Starting system:

 Electric

Battery:

12V, 4Ah

DIMENSIONS

Wheelbase:

800mm

L*W*H:

1230x740x800mm

Seat Height:

 550mm

Min ground clearance:

70mm
